2500L Brewpub Brewery Equipment
Configuration
A brewhouse may refer to a company that brews beer or the building used for this process, but it’s also a collective term for all the components a brewery will need for the initial brewing stage.
These components typically include the following:
• Mash mixer
• Lauter tun
• Boil kettle
• Whirlpool
• Hot liquor tank
| 1.Malt Milling System | Mill machine | Stainless steel/Carbon steel |
| Grist case | Stainless steel | |
| Flexible conveyor | Outer PPR or Stainless steel | |
| 2.2500L Brewhouse System | Mash tun | Inner:3mm;outer:2mmMotor agitationSteam jackets/Electric elements/Fire direct heating |
| Lauter tun | Inner:3mm;outer:2mmRack system;False bottom filter | |
| Kettle tun | Inner:3mm;outer:2mmSteam jackets/Electric elements/Fire direct heating | |
| Whirlpool tun | Inner:3mm;outer:2mmSide tangent whirlpool inlet | |
| Hot water tank | Inner:3mm;outer:2mmSteam jackets/Electric elements/Fire direct heating | |
| Accessories | Mash pump;;Heat exchange plate;Hop back system; Brewhouse Pipes; | |
| 3.Fermentation System | Fermentation tank | Pressure:3Bar;Inner:3mm;outer:2mm;with insulation;Cooling jackets; |
| Accessories | Yeast adding Tank; | |
| 4.Cooling System | Glycol water tank | Inner:3mm;outer:2mm |
| Accessories | Chiller; Glycol water pump; Pipes and Valves; | |
| 5.CIP System | Acid tank | Pump; Pipes and Valves |
| Disinfection Tank | ||
| Trolley | ||
| Accessories of the CIP System | ||
| 6.Control System | Automatic/Semi-auto | |
| 7.Filtering System | Candle type diatomite filter/Membrane filter/Bag filter | |
| Bright beer tank | Double-layer with insulation; | |
| 8.Filling System | Glass bottle line | Capacity:800-1200 BPHWashing heads:8;Filling heads:8;Capping heads:3Optional:Capacity:1500-2000 BPHWashing heads:16;Filling heads:16;Capping heads:6 |
| Canning line | Capacity:1000-1500 CPHFilling heads:12;Capping heads:1 | |
| Keg system | Keg filling machine;Keg washing machine;Keg washing and filling unity machine; | |
Glycation Details
1. Inside heating device
2. Upper Interior Lauter Tun
3. ring filtration pipe
4. False Bottom-Back
5. manhole
6. inside stir
7. buffer tank
8. Grain door
9. Feed water mixer
Fermenter Detail
Content Gauge
Inside of FV
Manhole
Racking Arm
Sample Vavle
Spunding Valve
product Package
LCL(Less Container Load)
1.Pack by EPE(Pearl Wool)
2.Cover by Plastic Film
3.Load in Wooden Case
4. Fix by Attaching Strap in the Case
5.Close by Nails&tight by attaching strap finally
FCL(Full Container Load)
1.Pack by EPE(Pearl Wool)
2.Cover by plastic film
3.Fix on the Iron frame attaching strap
4.Load onto the container
5.Fix the tank to the wall of container by attaching strap
Accessories For Auxiliary Machines
Hops gun
Plate heating exchanger
Steam Boiler
Weld Polishing
| Output/Brew | 25HL |
| Brew/Week | 6~12 |
| Output/Week | 150~300HL |
| Electric Supply | 3phase/380(220, 415,440…)v/50 (60)Hz Single Phase/ 220(110, 240…)v/50(60)Hz |
| Heating Source | Steam/Directly Fired |
| Area Request | >140M2 |
| Brewmaster | 2 |
Note: 1hl=100liter; 1Gallon=3.7854liter; 1Barrel (BBL) =117Liter;
| Item | Production capacity | Volume in US Gallon | Heating area | Tank diameter | Height |
| SP-50 | 50L/day | 14US Gallon | 0.15㎡ | 550mm | 1500mm |
| SP-100 | 100L/day | 26US Gallon | 0.25㎡ | 650mm | 2000mm |
| SP-200 | 200L/day | 53US Gallon | 0.25㎡ | 850mm | 2200mm |
| SP-300 | 300L/day | 79US Gallon | 0.3㎡ | 950mm | 2500mm |
| SP-500 | 500L/day | 132US Gallon | 0.5㎡ | 1160mm | 2800mm |
| SP-600 | 600L/day | 158US Gallon | 0.6㎡ | 1220mm | 2350mm |
| SP-700 | 700L/day | 185US Gallon | 0.7㎡ | 1250mm | 2380mm |
| SP-800 | 800L/day | 212US Gallon | 0.8㎡ | 1260mm | 2400mm |
| SP-1000 | 1000L/day | 264US Gallon | 1.0㎡ | 1360mm | 3000mm |
| SP-1500 | 1500L/day | 396US Gallon | 1.5㎡ | 1520mm | 2900mm |
| SP-2000 | 2000L/day | 528US Gallon | 2.0㎡ | 1760mm | 3150mm |
| SP-2500 | 2500L/day | 660US Gallon | 2.5㎡ | 1800mm | 3200mm |
| SP-3000 | 3000L/day | 792US Gallon | 3.0㎡ | 1860mm | 3800mm |
| SP-5000 | 5000L/day | 1320US Gallon | 5.0㎡ | 2260mm | 4400mm |
